Heat Transfer System One to Two Room Kit

Available from Stock

HT02 R1 Duct 2-Room Heat Transfer Kit

Double the comfort. No extra power bill.

Don’t let that extra heat go to waste—put it to work in two rooms where you need it most. The HT02 R1 Duct 2-Room Heat Transfer Kit is a smart, energy-efficient way to spread warmth more evenly across your home—without the need for extra heating appliances.

If you have a toasty living room and a couple of cooler bedrooms, this system quietly transfers excess warmth using a high-performance inline mixed flow fan and insulated R1.0 ducting. It’s perfect for homes with log burners, pellet fires, or any heat source that creates more warmth than one room needs.

With 12 metres of R1.0-rated insulated ducting included (and capable of runs up to 15 metres), this system is ready for longer installations—ideal if your rooms are spread out.

Why You’ll Love the 2-Room Kit:

Warms two rooms at once using heat you’re already generating
Reduces heating costs by making better use of your existing system
No major renovations required – install it with minimal disruption
Insulated ducting retains heat and dampens sound
Powerful, quiet fan for consistent airflow without the noise
Downjet grilles push warm air directly to the floor for faster comfort.

Whether you're taking the chill off two bedrooms, warming a home office and hallway, or simply spreading the heat more evenly, the HT02 2-Room Kit brings balance, comfort, and energy efficiency to your home.

Smart. Simple. Warmth, shared.

Components

1 x 150Ø Mixed Flow Inline Fan
1 x 150x150-150Ø Inlet Ceiling Grille
2 x 150Ø Downjet Outlet Ceiling Grille
2 x 150Ø 6m R1.0 Rated Flexible Duct
1 x Y Branch 150-150-150
1 x Room Thermostat
1 x Roll PVC Duct Tape

Specifications

	HT02 Fan Fan Type: 150 mm mixed-flow inline fan, engineered for efficient, quiet air transfer between rooms. Motor: Single-phase motor operating at 230–240 V, 0.55 kW. Designed for durability and continuous operation. Airflow Performance: Delivers up to 147 L/s (530 m³/hr), ideal for distributing warm air and balancing temperatures throughout the home. Sound Level: Quiet operation at 44 dB(A) measured at 3 m — low-noise performance suitable for residential environments. Ducting Capability: Supports duct runs of up to 15 m, making it well-suited for both small and large-scale heat transfer systems.
	HT02 Intake Grille Size: 150 mm x 150 mm faceplate with a 150Ø spigot connection, suited for standard ducting systems. Material & Design: Lightweight, durable plastic with an eggcrate-style grille to ensure maximum airflow and minimal resistance. Airflow Efficiency: Optimised design promotes high-volume air intake, supporting efficient system performance. Maintenance: Features a removable faceplate for easy access and cleaning—no tools required. Appearance: Low-profile, clean finish designed to blend seamlessly into ceilings or walls in modern residential interiors.
	HT02 Downjet Grille Airflow Direction: Designed to direct warm air straight downward, promoting faster and more even heat distribution throughout the room. Outlet Size: 150 mm (150Ø) neck connection for compatibility with standard ducting and effective, concentrated airflow. Functionality: Optimised to push warm air to the occupied zone, reducing stratification and improving comfort levels. Design: Slim, low-profile construction for a clean, unobtrusive ceiling installation. Blends seamlessly with modern interiors.
	150Ø 6m Insulated R1.0 Duct Strong, durable, and built to last. The R1.0 insulation layer — Enhances energy efficiency and reduces condensate buildup. Size: 150mm (150Ø), 6m length for optimal air transfer Durability: Reinforced construction resists tearing in the roof space Insulation: R1.0 insulation reduces energy loss and maintains warmth Flexibility: Ideal for tight spaces, offering easy installation and reliability
	150Ø Equal Y Branch (150 x 150 x 150) Designed to split one duct line into two, this galvanised steel Y branch is perfect for directing airflow to multiple rooms or zones. With equal 150 mm diameter spigots on all three ends, it ensures smooth, balanced distribution and efficient system performance.
	Room Thermostat: The HT01 Room Thermostat monitors the room temperature and activates the system to prevent overheating and save energy. Activation: Turns on when your desired temperature is reached. Comfort: Ensures a balanced and comfortable home temperature. We’ve chosen to supply a basic room thermostat with our heat transfer systems. While digital thermostats may look modern, their added features often come at a higher cost without offering practical benefits for most installations. Our focus is on reliable, cost-effective temperature control—simple to use, and perfectly suited to the job. If you would prefer to upgrade to a digital thermostat, just let us know—we’re happy to arrange it.
