Frameless Round Ceiling Vent 200mmø

Frameless Round Ceiling Vent – 200mm Ø

Product Overview

The 200mm Frameless Round Ceiling Vent is a modern, discreet air distribution solution designed for both supply and extract ventilation systems.

Featuring a slimline, plaster-in design, the vent integrates neatly into plasterboard ceilings, leaving a subtle circular opening without a prominent external frame.

Ideal for residential and architectural projects where a clean, minimalist ceiling finish is preferred.

Seamless, Minimalist Design

The frameless construction allows the vent to blend into the surrounding ceiling, creating a neat, unobtrusive finish.

Designed for recessed installation, the narrow-edge profile minimises the visible border, while the white, paintable surface can be finished to match the surrounding ceiling.

Adjustable Airflow Control

The vent features an adjustable centre section that can be screwed in or out to regulate the airflow opening.

This allows airflow to be adjusted to suit the requirements of the ventilation system, making it suitable for both supply and extract air applications.

Clip-On Design with Insect Mesh

The vent features a clip-on construction with an insect mesh designed to help prevent insects from entering through the ventilation opening.

The mesh is not an bug mesh and is not intended to remove dust or fine airborne particles.

Key Features

• Frameless plaster-in design for a minimalist ceiling finish

• 200mm nominal duct connection

• Estimated airflow: 55–90 L/s

• Suitable for supply and extract ventilation

• Adjustable screw-type centre for airflow regulation

• Slimline, narrow-edge design

• Clip-on construction

• Insect mesh

• White, paintable finish to match ceiling colour

• Durable ABS plastic construction

• Ceiling-mounted installation

• Suitable for residential and commercial applications

Specifications

Specification	Details
Product	Frameless Round Ceiling Vent
Nominal Size	200mm
Duct Connection	200mm nominal
Material	ABS Plastic
Finish	White, paintable
Design	Slimline, narrow-edge
Airflow Adjustment	Screw-adjustable centre
Mesh	Insect mesh
Construction	Clip-on
Application	Supply or extract ventilation
Installation	Ceiling mounted, plaster-in

Airflow Information

Estimated airflow range: 55–90 L/s

Please note: This airflow range is indicative only. Manufacturer-tested airflow, pressure drop and acoustic performance data are not currently available. Actual airflow will depend on system pressure, ductwork configuration, insect mesh condition and adjustment of the centre section.

Installation Information

Designed for recessed installation into plasterboard ceilings, allowing the vent to sit neatly within the finished ceiling surface.

The clip-on construction provides access to the vent component, while the adjustable centre allows airflow regulation.

The visible surface can be painted to match the finished ceiling.
